The physician receiving ECG results may question what these mean in some instances, what is significant
and finally, what to do with the results. This is a brief review of the terminology and implications of ECG
interpretations to assist providers in their decision making.
Intraventricular Conduction Delay
This is also known as conduction delay, IVCD, or incomplete right bundle branch block (iRBBB).
It is mostly a variant of normal, especially in athletes. The difficulty for cardiologists reading an
electrocardiogram with conduction delay without seeing the patient is that it is tempting to label it as
normal since the vast majority of the patients with this, in fact, have a normal heart. But since there is a
small proportion of patients who do have an abnormality, a decision on whether or not the patient
should be evaluated further depends on the reasons for the electrocardiogram.
Cause for concern: This may be a manifestation of RV enlargement in situations such as an atrial septal
defect or anomalous pulmonary venous return. Sometimes medications can cause conduction delay,
this is felt to be benign. If a murmur is present or there are potential cardiac symptoms or the QRS
duration is >120msec cardiology evaluation is warranted.
Sinus Arrhythmia
This is invariably normal and physiologic. Unfortunately, when it is very pronounced, it can be a cause
for concern in the patient or parents who interpret the irregular rhythm as abnormal or possibly (in
medical families) as a sign of atrial fibrillation. Frequently these situations result in sinus tachycardia
because of the fear reaction. Holter monitors interpreted by non-pediatric cardiologists may label this
as recurrent SVT.
Left Axis Deviation (LAD)
This refers to the mean QRS vector being less than 0 degrees. Cause for concern is that it can be
associated with an AV canal defect or inlet VSD. Other causes include left-sided heart disease, single
ventricles, and cardiomyopathies.
It is frequently a normal variant in asymptomatic older children. However, the reason for performing the
ECG in part should dictate whether cardiology evaluation is warranted. In infants or children with
murmurs or a family history of cardiomyopathy, cardiology evaluation is warranted. If the mean QRS
vector is greater than -10 degrees (example -30 degrees), cardiology evaluation is warranted as is the
case if there is LAD along with other findings (T wave inversion, atrial enlargement, conduction delay,
etc.)
Right Axis Deviation (RAD)
Most of these are normal in the range of 90-100 degrees. Cardiology evaluation is recommended for >120 degrees.
First-Degree AV Block
This refers to PR prolongation > 200msec; however, it is a rate-dependent definition, thus shorter
intervals at low heart rates also qualify.
The majority of cases are normal variants.
Pathological causes for this relate to the underlying reason for the first-degree AV block. With an atrial
septal defect, the atrial enlargement can prolong the time for conduction from the sinus node to the AV
node. These individuals will have a murmur and may also have IVCD (see above). A patient with a
history of possible SVT may have first degree AV block because of the presence of “dual AV node
physiology,” which is the presence of two pathways to the AV node that predispose to AV node reentry
SVT, the most common type of SVT with onset in the adolescent and teen years. Finally, there are
occasional cases of AV node dysfunction that may show first-degree AV block.
Consider cardiology evaluation in symptomatic patients or those with a heart murmur or PR > 400ms.
Second Degree AV Block, Wenckebach Type (MobitzType 1)
This is a gradual prolongation of the PR interval followed by a dropped QRS complex after a P wave. It is
commonly seen in normal children during deep sleep on Holters or inpatients being monitored on
telemetry. The reason for this being considered benign during sleep is that the high vagal tone during
deep sleep is felt to be a physiologic cause. It is not considered normal when individuals are awake. The
exception to the rule is highly-trained athletes who have increased vagal tone manifesting at rest. If in
doubt, contact a cardiologist to discuss the need for referral.
Sinus Pauses During Sleep
Pauses of less than 2 seconds are often seen in normal individuals during sleep, but generally there will
just be one to three of these, not dozens. More frequent pauses or pauses >2.5 seconds should be
evaluated.
Variants of Normal Rhythm
These are not of concern and include:
Sinus bradycardia (rates >30)
Sinus arrhythmia
Low right atrial rhythm or ectopic atrial rhythm (NOT atrial ectopic tachycardia)
Wandering atrial pacemaker
Junctional rhythm
Rare PACs and rare PVCs
Left Ventricular Hypertrophy
Up to 40% of highly trained athletes with a normal heart may show voltage criteria for LVH (SV1+RV6 35mm), the same is also true for many African-American people.
Patients with hypertrophic cardiomyopathy will also show LVH but in these cases there are frequently
other accompanying abnormalities such as T wave inversion, ST depression, QRS axis deviation,
complete bundle branch block, atrial enlargement.
Therefore the indication for cardiology evaluation is either symptoms, a murmur, family history of
cardiomyopathy (“enlarged heart”), sudden death or the presence of LVH PLUS other ECG abnormalities.
Please make sure all first degree relatives of a patient diagnosed with hypertrophic cardiomyopathy are
evaluated.
Bundle Branch Block
True complete (not incomplete) bundle branch block, BBB, either right or left warrants cardiology
evaluation.
Early Repolarization
This is often seen in teen athletes and is usually normal. It consists of J point elevation, ST elevation and
some terminal QRS slurring in the inferior and/or lateral leads. This is different than ST elevation in
many leads and one should be suspicious in a patient with a history of pericarditis (chronic pain,
difficulty lying supine, nausea or decreased appetite, and audible cardiac rub).
Q Waves
Small narrow Q waves (less than 40ms or one small box) in one or two leads may be normal but
otherwise wider or deeper Q waves warrant further evaluation
Prolonged QTc
The most common cause for a prolonged QTc seen by cardiologists on a daily basis are drug overdoses
and ingestions. Other benign causes are low K, Ca, Mg, use of tricyclic antidepressants and
erythromycin. It would be prudent to repeat an ECG on these patients when the ingestion or electrolyte
imbalance is completely resolved.
The best assessment of the QTc is using the Bazett formula, not Hodges. Unfortunately, the presets for
ECG machines in the majority of pediatrician’s offices is the Hodges formula. All children’s hospitals and
our group use Bazett. Please consider having your ECG tech contact our office medical assistants for
advice on changing the preset formula.
Bazett QTc= QT(in msec)/ square root of RR (in msec)
Normal: Male up to 0.425, females up to 0.444. Consider the QTC prolonged and worthy of further
investigation if 0.460 or greater. Note that ECG machine QTc values are often incorrect and it can take
an experienced reader to correctly identify a prolonged QTc. This is the reason that the indication for
the ECG is so important: History of seizures, syncope, family history of sudden death or Long QT
syndrome will prompt the reader to manually measure a QTc. Please make sure all first degree relatives
of a person with Long QT syndrome are evaluated.
African-American Athletes
In African-American athletes a common normal variant ECG finding is the combination of left ventricular
hypertrophy plus J point elevation (early repolarization) with a convex pattern and T wave inversion in
leads V1-V4.
Two or More “Borderline” ECG Findings
Consider cardiology referral.
Helpful references
Pediatric Cardiology Center of Oregon, www.pccoforegon.com, phone 503-280-3418, fax 503-284-7885.
Simplified Pediatric Electrocardiogram Interpretation. William N. Evans et al.,
https://fhs.mcmaster.ca/pediatrics/documents/simplifiedEKGinterpretation-clinicalpediatrics2010.pdf.
This is a very easy to use and simple guide to reading Pediatric ECGs.
Electrocardiographic interpretation in athetes: the “Seattle Criteria”. Jonathan A. Drezner et al., Br J
Sports Med, 47, 122-124, 2013.
International criteria for electrocardiographic interpretation in athletes. BJSM Online
First, published on March 3, 2017 as 10.1136/bjsports-2016-097331
